Release Notes

New for the 1.6.7 Release

The following features and improvements have been added for this release:

General Application

Added support for Korean
Added an uninstall script for Mac to application CD
Added support for new Apple iMacs that use GB-LED technology

Bug Fixes

Fixed an issue with export of Tab Delimited data in Measure Chart workflow
Fixed an issue where CGATS data was not saved correctly for different illuminants and observers
Made the Reflectance Spectrum check box setting sticky and enabled by default for Custom CGATs dialog where spectral data is present
Fixed a problem with ProfileMaker 5 CGATS files exported from PatchSetEditor

Installation and Registration

Administrative rights are required to install and uninstall the software.

Do not connect measurement devices until the software installation is complete and the system has restarted.

The i1Profiler Dongle, i1Display Pro or the i1Pro 2 must be connected in order to register your i1Profiler solution.

Minimum suggested hardware/software requirements:

Macintosh®:

MacOS X 10.8.x through MacOS X 10.12.x
All Operating Systems should have the latest updates installed
2GB RAM
Intel® Core 2 Duo Processor
2GB of available disk space
Powered USB Port
Monitor resolution of 1024x768 pixels or higher
Dual display support requires either 2 video cards or a dual head video card that supports dual video LUTs being loaded
Latest drivers for video card installed
DVD drive or high-speed Internet connection required for software install, download and automatic software update
User must have Administrator rights to install and uninstall the application

Windows®:

Microsoft® Windows 7® 32 or 64 bit
Microsoft® Windows 8® 32 or 64 bit
Microsoft® Windows 8.1® 32 or 64 bit
Microsoft® Windows 10® 32 or 64 bit
All Operating Systems should have the latest updates and Service Packs installed
2GB RAM
Intel® Core 2 Duo or AMD Athlon™ 64 X2 or better CPU
2GB of available disk space
Powered USB Port
Monitor resolution of 1024x768 pixels or higher
Dual display support requires either 2 video cards or a dual head video card that supports dual video LUTs being loaded
Latest drivers for video card installed
Network adaptor installed and driver loaded
DVD drive or high-speed Internet connection required for software install, download and automatic software update
User must have Administrator rights to install and uninstall the application

Known Issues

Test chart and workflow files made for the i1iO and i1iO2 devices in earlier versions of i1Profiler (before version 1.6.0), will have a different patch height when loaded into i1Profiler. You will need to adjust the patch height to the correct dimension and then re-save the file for current and future use.

The Reference Files for the ColorChecker SG and ColorChecker 24 for scanner profiling have been updated. These new reference files apply well to ColorChecker SG and 24 charts manufactured after November 2014. For ColorChecker editions prior to November 2014, please use the former Reference Files, which can be downloaded from www.xritephoto.com, including instructions how to replace and apply them in i1Profiler.

Profiling and optimizing profiles with very large patch sets (>3000) will require a very large amount of RAM. If profiling fails, reduce the amount of patches in the test chart.

The i1Profiler UI and text may appear very small on 4k/5k displays.

Monitor calibration does not work when multiple monitors are in mirror mode (this issue affects Window® installations only.) Special Note: On Windows XP, if a display is removed from a system, the operating system will put the primary display in mirror mode even though the secondary display has been removed. In this case, the user will get an enumeration error. This error can be dismissed and the user will still be able to make a profile.

i1Profiler does not support the calibration of displays connected via AirPlay.

If you have problems loading the display profile after it has been created or if the system cannot load the display LUTs, turn off Automatic Display Control (ADC) on the measurement page and try again.

i1Profiler uses OpenGL to display the profile’s 3D gamut. If you encounter a problem with the gamut preview, make sure that your video card drivers are up to date.

i1Profiler can import CGATS measurement files from other applications. However, the color engine has been optimized to work with the patch sets generated within i1Profiler. The profile quality from profiles made entirely within the i1Profiler workflow will exceed profiles made from legacy charts and measurements. In the case of CMYK+N profiles, some legacy patch sets may not even build a profile successfully. It is strongly recommended that users build new charts within i1Profiler for CMYK+N profiling.

If you are using Ambient Smart Light Control when making your display profile, expect to get higher Delta E values in Display QA. This function optimizes profiles for visual appearance based on measured ambient conditions not for minimal Delta E.

The i1ProfilerTray does not update the time stamp on a rebuilt profile. If a profile is rebuilt using the ambient monitoring feature in the Tray, the original profile creation date is displayed instead of the rebuilt profile creation date.

The i1ProfilerTray application looks for connected displays at launch. If you disconnect or connect a display, the i1ProfilerTray will not see the change until it is restarted, the user logs out or the system is restarted. On Windows the i1ProfilerTray can be restarted from the ProgramsStartup menu, on Mac, the tray is located in the same folder as the i1Profiler application.

The application may lose its connection to a measurement device if the computer goes into sleep or hibernation mode. If this happens, disconnect and reconnect the device to restore the connection.

Installation of older applications that use the previous version of X-Rite Device Services may cause i1Profiler to not connect with devices or to not launch. If this occurs, reinstall i1Profiler to restore the latest Device Services.

If you encounter any problems connecting to your measurement device, please disconnect and reconnect the device to restore the connection.

Make sure your i1iSis power button is on when you connect the USB cable. If you connect with the button off, then turn the power on, the i1iSis will not be seen.

The i1iO device does not support single row charts.

You cannot measure an optimization test chart that contains patches extracted from an image if you are using an i1iO or i1iO2.

The version of XRD being installed by i1Profiler causes an issue in ColorPort where targets containing partial rows cannot be read using the i1iO table. The instrument will measure the row, but the data does not come into ColorPort. This affects ColorPort 2.0 and later.

Change History

Version 1.6.3

General Application

Implemented new “All in One” measurement mode for the i1Display Pro to improve the measurement stability for certain displays and projectors. (Only affects Rev. B devices.)
Added support for Microsoft® Windows 10®.
Incremental enhancements to the infrastructure of the product as well as the color engine have been implemented.

Bug Fixes

Fixed issue where test charts saved in the PDF format were low resolution and were in the incorrect color space.

Fixed issue where some ColorPort xml test chart reference files were not reading with the i1iSis and i1iSis 2 devices in the Measure Reference workflow.

Fixed issue where IdeaAlliance P2P25Xa and P2P51 charts could not be read with the i1iSis and i1iSis 2 devices in the Measure Reference workflow.

Fixed issue where CMYK+N channel names were not being written into the profile correctly.

Fixed issue where custom profile white points were not getting written into the profile correctly.

Fixed issue where the i1iO and i1iO2 would frequently switch to spot mode during measurement.

Version 1.6.1

Bug Fixes

Fixed issue where users could not save PDF files for single-page test charts.
Fixed issue where the standard Japan Color Proof Equip/Operation Coated target was getting reformatted for the i1iO with an i1Pro 2.
Fixed issue where XYZ data was not properly written into CGATS files.

Version 1.6.0

Added support for dual scan mode (M1 and M2) for the i1iO table. (User must have the i1Pro 2 device as well as an i1iO 2 table running firmware version 1.0.7 or later.)

Added support for the new i1iSis 2 with M1 measurement condition.

The Patch Set Editor allows users to create custom patch sets and to modify existing patch sets from i1Profiler, ColorPort, MeasureTool and other applications.

The Patch Set Editor import supports:

i1Profiler Patch Set Files (*.pxf)
i1Profiler Test Chart Files (*.txf)
i1Profiler Measurement Files (.mxf)
i1Profiler ICC Profiles (*.icc and *.icm)
ColorPort XML Files (*.xml)
CGATS Text Files (*.txt)
CxF Files (*.cxf)
Tab-delimited Text Files (*.txt)

The Patch Set Editor export supports:

i1Profiler Patch Set Files (*.pxf)
i1Profiler CGATS Files (*.txt)
Custom CGATS Files (.txf)
ProfileMaker5 CGATS Files (*.txt)
CxF Files (*.cxf)
Tab-delimited Text Files (*.txt)

The Patch Set Editor will also allow users to manually create custom patch sets, add or remove patches from existing patch sets and change the order of patches within a patch set.

i1Profiler Publish users can now see detailed measurement data for individual patches within a measured test chart. To access the information, double-click on a measured patch within any printer-related Measurement Page. (Does not apply to display measurements.)

Information displayed includes:

Patch ID
Patch Location
Patch Visualization
Patch Recipe
Spectral Curves
Colorimetric Data
Density Data

Added the ability to specify a target white point using u’,v’ coordinates.

Added the ability to specify a custom target black point or measure a secondary display to set a target profile black point.

Added the ability to change the reference data for the ColorChecker 24 and ColorChecker SG. These reference files are now located with the other scanner reference files in the i1Profiler Assets.

Added the following targets to Printer QA:

IDEAlliance ISO 12647-7 2013 Control Wedge i1Pro
IDEAlliance ISO 12647-7 2013 Control Wedge i1iSis
IDEAlliance TC2011 Color Control Wedge i1iSis
IT8-7.4 Color Control Wedge i1iSis
P2P25Xa Color Control Wedge i1iSis

General Application

In addition, some incremental enhancements to the infrastructure of the product as well as the color engine have been implemented.

Fixed issue (Mac Only) where i1Profiler would crash at launch if a secondary display or projector was connected to a system using a VGA/Display Port or VGA/ Thunderbolt adaptor.

Fixed issue where scanner profiles were failing due to a reported contrast error.

Fixed issue where Hasp dongle driver was crashing on MacOS X 10.10.x.

Version 1.5.6

i1Pro SDK Fix: Fixed a bug in the i1Pro SDK that caused slightly false measurement errors when calculating M1 (D50) & M2 (UVCut) spectral values. It is important to note that this issue did not affect M0 (tungsten only) measurements.
General Application

In addition, some incremental enhancements to the infrastructure of the product as well as the color engine have been implemented.

Version 1.5.4

Support for New Version of i1Display Pro: i1Profiler has been updated to support a new revision level of the i1Display Pro hardware and firmware.

General Application: In addition, some incremental enhancements to the infrastructure of the product as well as the color engine have been implemented.

Version 1.5.0

Device Link Profiling: Added the ability to create Device Link profiles.

NOTE: Users must have an i1Pro 2 with an i1Profiler Publish license OR a dongle with an i1Profiler Publish license to unlock device link profiling.

Dual Spot Measurement for i1iO: Added the ability to perform dual mode measurements with the i1Pro 2 in a supported i1iO table. This is spot mode only.

Display and Projector: Better support for Plasma Displays with the i1Display Pro: Fixed issue in previous releases where plasma displays yielded poor calibration results when measured with an i1Display Pro.

Display and Projector: Enhanced the Projector Location algorithm for more accurate location of projected image on screen.

Printer QA: Added the Ugra/Fogra Media Wedge CMYK v3 LFP for large format printing.

Scanner Profiling: Added support for HutchColor (HCT) family of scanner targets. Removed the resolution restrictions for scanned targets.

Patch Generation: Fixed an issue where there was a slight discrepancy in the CMYK device values between the CGATS and TIFF files created for a given patch set.

Tray Application: After installation and restart, the Tray application will no longer launch automatically. The Tray is only activated if a user selects the Profile Reminder and/or the Ambient Monitoring feature found in the Display Profiling branch.

Tray Application: Fixed the issue where the Tray application was preventing the MacOS from shutting down.

General Application: In addition, some incremental enhancements to the infrastructure of the product as well as the color engine have been implemented.

Version 1.4.2

Scanner Profiling: Added support for the following scanner targets:

X-Rite ColorChecker 24
X-Rite ColorChecker SG
LaserSoft Reflective IT 8.7/2
LaserSoft Transmissive 4x5 and 35mm IT 8.7/1
Wolf Faust Reflective IT 8.7/2
Wolf Faust Transmissive 4x5 and 35mm IT 8.7/1

CGATS Functionality: Improved the support for 'SampleID', 'SAMPLE_NAME', and 'Sample_Loc' column types.

Made enhancements for custom output column selections. Made location information content optional in 'SAMPLE_NAME' column.

Added support for P2P and other popular single-page color control wedges. Dropped support for MacOS 10.5.x (Leopard.)

Version 1.4.0

Note: The 1.4.0 release was distributed on a limited basis to OEM customers. It was not put into wide release.

Added basic scanner profiling to the application.

Fixed issue where channel names were incorrectly assigned in CMYK+N profiles.

Fixed memory issue where application would fail or crash when trying to measure very large (greater than 3000 patches) test charts.

Changed System requirements from 1 GB of RAM to 2 GB RAM. Added support for MacOS 10.8.x (Mountain Lion.)

Version 1.3.2

Fixed issue where i1Profiler would hang during display calibration (Windows 7 64- bit only).

Version 1.3.1

Fixed issue where i1Profiler assets were not being installed correctly.

Added the Process Standard Rotogravure (PSR) characterization data (published in 2009 by bvdm/ECI/ERA/FOGRA) to the Printer Quality workflow.

Added the Russian translation of the license agreement to the installer.

Version 1.3.0

Added support for the new i1Pro 2 Device.

New chart layouts for i1Pro 2 with smaller default patch size and removal of spacer lines between patches.

The i1Pro 2 supports three measurement conditions; M0, M1 and M2. The user must be in dual scan mode to get access to all three.

The i1Pro 2 device was added to the OBC workflow. Can transfer license information from i1Pro to i1Pro2.

The i1Pro 2 can be used in legacy mode to measure charts previously created for the i1Pro.

Can now use the included ColorChecker chart as OBC reference standard.

Added the Measure Reference feature. User can import a test chart reference file from ProfileMaker 5 and measure a previously printed test chart.

Added the Measure Chart capability. User can specify measurement device and number of rows and columns for a previously printed test chart and measure.

Added the ability to change the white point of printer profiles. The white point can be specified in Lab, extracted from a saved measurement or extracted from an ICC profile.

Fixed issue in CMYK+N profiling where extra colors were not being handled correctly within the user interface causing measurement issues.

Fixed CMYK+N issue where +N color names and values were not getting written into the DCS file for saved test charts.

Improved handing of CGATS measurement data.

Added two new photo paper sizes; 8x10 in. (203x254 mm) and 8x12 in. (203x305 mm).

Changed default page orientation to landscape for both i1Pro and i1Pro 2. Added Russian language support.

Version 1.2.0

Added the ability to balance RGB controls during display calibration. Improved ADC’s functionality and connectivity for all platforms.

Added the reporting of target and measured values for luminance, white point and contrast ratio during display profiling.

Fixed issue where profiling and QA of second display was producing inaccurate results (Mac only).

Added the ability to calibrate EIZO ColorEdge displays using ADC.

Added the ability to select M0 or M2 measurements for profile creation (when both measurements are present.)

Improved CGATS exporting. Allows user to customize exported CGATS data for multiple uses.

Added support for the Japan Color standard in Printer QA.

New X-Rite Device Services solves Japanese connection problems with i1Display, iO with i1Pro Rev. B problem and various connection issues.

Fixed issue where profile could not be made if the black ink on the test chart was too chromatic.

Added the ability to do small (119), medium (220) and large (478) patch sets when doing advanced display calibration.

Added the ability to specify a target contrast ratio for the display to match the ICC standard PCS black point (287:1).

Added the ability to use the contrast ratio of a printer profile as the target contrast ration for a display profile.

Miscellaneous minor bug fixes.

Version 1.1.0

Support for the i1Display monitor calibrator.

Ambient Smart Light Control adjusts display profiles based on the ambient lighting condition of the viewing area.

Flare Correct provides the capability to measure and correct for incident light falling on the display.

Display QA has been improved allowing users to test their display against known standards, spot colors and images.

Display Trending tracks the color capability of each display over time.

Improved data handling for MO and M2 measurements as well as improved handling of CGATS file made within and from outside i1Profiler.

The i1ProfilerTray application monitors all displays on a system, provides profile reminders and can rebuild the display profile in real time based on changing ambient light conditions (i1Display only.)

Open Source/ 3rd Party Software

All Open Source and 3rd Party License agreements and credits are located in the following locations:

Windows: Program Folder/Credits

Mac: Application package/Contents/MacOS/Credits

I1 Display Pro (PC/Mac) is a Commercial software in the category Business developed by X-Rite Pantone Products. The latest version of i1 Display Pro (PC/Mac) is currently unknown. How to download geometry dash full version for free.

All Product Support

This list is an alphabetized by product name, and includes both active and discontinued X-Rite product support pages. Products with an '*' are Out of Production.

3589ABCDEFGHIJKLMNOPQRSTUVWXYZ

3

301 — Benchtop Transmission Densitometer
331 — Portable Transmission Densitometer*
331C — Portable Transmission Densitometer
341 — Portable Transmission Densitometer*
341C — Portable Transmission Densitometer
361T — Benchtop Transmission Densitometer
369 — Benchtop Transmission Densitometer
396 — Benchtop Transmission Densitometer*

5

504 — Portable 0°/45° Spectrodensitometer
508 — Portable 0°/45° Spectrodensitometer
518 — Portable 0°/45° Spectrodensitometer*
520 — Portable 0°/45° Spectrodensitometer*
530 — Portable 0°/45° Spectrodensitometer*
552 — Portable 0°/45° Spectrodensitometer*

8

880 — Automatic Strip Reading Densitometer*
881 — Automatic Strip Reading Densitometer*
890U — Automatic Strip Reading Densitometer*
891U — Automatic Strip Reading Densitometer*
892 — Automatic Strip Reading Densitometer*

9

939 — Portable 0°/45° Spectrophotometer*
962 — Portable 0°/45° Spectrophotometer
964 — Portable 0°/45° Spectrophotometer

A

Appearance Exchange Format (AxF™) — Data Exchange Format
ATS — Pressroom Scanning Spectrophotometer*
ATS Publication — Pressroom Scanning Spectrophotometer*

C

CA22 — Portable 0°/45° Spectrophotometer*
CAPSURE™ Cosmetic — Portable 0°/45° Colorimeter
CAPSURE — Portable 0°/45° Colorimeter
CAPSUREme — Utility Software
CarFlash — Non--Contact Industrial Spectrophotometer
CF57 — Benchtop 0°/45° Spectrophotometer
Ci4100 — Benchtop 0°/45° Spectrophotometer
Ci4200 — Benchtop 0°/45° Spectrophotometer
Ci51 — Portable Sphere Spectrophotometer
Ci52 — Portable Sphere Spectrophotometer
Ci60 — Portable Sphere Spectrophotometer
Ci61 RTL — Portable Sphere Spectrophotometer
Ci62 — Portable Sphere Spectrophotometer
Ci62 RTL — Portable Sphere Spectrophotometer
Ci64 — Portable Sphere Spectrophotometer
Ci7600 — Benchtop Sphere Spectrophotometer
Ci7800 — Benchtop Sphere Spectrophotometer
Ci7860 — Benchtop Sphere Spectrophotometer
Color i5 — Benchtop Sphere Spectrophotometer*
Color i7 — Benchtop Sphere Spectrophotometer*
Color iMatch — Formulation Software
Color iQC — Quality Assurance Software
Color iScan — Quality Assurance Software*
Color iTextile Software — Quality Assurance Software*
ColorCert Desktop Tools — Quality Assurance Software
ColorCert Repository Server — Quality Assurance Software
ColorCert Scorecard Server — Quality Assurance Software
ColorChecker 18% Grey Balance — Photographic Target
ColorChecker Classic — Photographic Target
ColorChecker Digital SG — Photographic Target
Colorchecker Greyscale — Photographic Target
Colorchecker Mini — Photographic Target*
Colorchecker Passport Photo — Photographic Target
Colorchecker Passport Software — Photographic Target
Colorchecker Passport Video — Photographic Target
ColorChecker Video — Photographic Target
Colorchecker White Balance — Photographic Target
ColorDesigner Plus — Retail Paint Formulation Software
ColorElite Software RGB — Calibration Software*
ColorEye 7000A — Benchtop Sphere Spectrophotometer*
ColorEye 740 — Benchtop Sphere Spectrophotometer*
ColorEye XTH — Portable Sphere Spectrophotometer*
ColorEye XTS — Benchtop Sphere Spectrophotometer*
ColorMaster Software — Quality Assurance Software
ColorMunki Create — Calibration Hardware & Software*
Colormunki Design — Calibration Hardware & Software*
Colormunki Display — Calibration Hardware & Software
Colormunki Photo — Calibration Hardware & Software
Colormunki Smile — Calibration Hardware & Software
ColorPicker — Utility Software*
ColorPort — Utility Software*
ColorQuality Software — Quality Assurance Software
ColorShop for Windows — Utility Software*
ColorShop X Analyze — Utility Software*
CounterTop 750 — Benchtop Sphere Spectrophotometer*

D

D19C — Portable 0°/45° Spectrophotometer*
DensiEye 100 — Portable 0°/45° Densitometer
DensiEye 700 — Portable 0°/45° Densitometer*
DensiEye 750 — Portable 0°/45° Densitometer*
Digital Finish Capture — Color Capture Service

E

EasyTrax — Scanning Pressroom Spectrophotometer
EFX QC — Quality Assurance Software
ERX130 — Non-contact Industrial Spectrophotometer
ERX30 — Non-contact Industrial Spectrophotometer
ERX31 — Non-contact Industrial Spectrophotometer
ERX40 — Non-contact Industrial Spectrophotometer
ERX54 — Non-contact Industrial Spectrophotometer
ERX55 — Non-contact Industrial Spectrophotometer
ERX56 — Non-contact Industrial Spectrophotometer
ESWin CLCC — Quality Assurance Software
ESWin QC — Quality Assurance Software
eXact — Portable 0°/45° Spectrodensitometer
eXact Densitometer — Portable 0°/45° Densitometer
eXact InkkeyControl — Quality Assurance Software
eXact Scan — Portable 0°/45° Spectrodensitometer
eXact XP — Portable 0°/45° Spectrodensitometer
Examolite — Luminary*
EZColor — ICC Profiling Software*
EZColor EPSON — ICC Profiling Software*

F

FM 100 Hue Test — Color Vision Testing Kit
FM Dichotomous D15 Test — Color Vision Testing Kit

H

Harmony Room — Custom Color Evaluation Room
Hubble — Home Theater Calibrator*
HueyPRO — Display Calibration Hardware & Software*
Home Visualizer — Utility Software*

I

i1Basic Pro 2 — Profiling Hardware & Software
i1Basic Pro UVCut — Profiling Hardware & Software
i1Basic Pro — Profiling Hardware & Software
i1Beamer — Profiling Hardware & Software*
i1Color Point — Utility Software*
i1Diagnostics — Photographic instrument diagnostics
i1Display 2 — Calibration Hardware & Software*
i1Display LT — Calibration Hardware & Software*
i1Display Pro — Calibration Hardware & Software
i1iO — Automated Scanning Table
i1iO 1st Generation — Automated Scanning Table*
i1iSis 2 — Automated Chart Reader
i1iSis 2 XL — Automated Chart Reader
i1iSis — Automated Chart Reader*
i1iSis With OBC — Automated Chart Reader*
i1Match — Calibration Software*
i1Photo Pro 2 — Calibration Hardware & Software
i1Photo Pro UV Cut — Calibration Hardware & Software
i1Profiler — Profiling Hardware & Software
i1Profiler D2LionEdition — Profiling Hardware & Software*
i1Publish — Profiling Hardware & Software
i1Publish Pro 2 — Profiling Hardware & Software
i1publish pro 2 Upgrade — Profiling Hardware & Software
i1Publish Upgrade — Profiling Hardware & Software
i1Share — Utility Software
i1Studio — Profiling Hardware & Software
i1Xtreme — Profiling Hardware & Software
iCColor — Profiling Hardware & Software*
iCFilm — Portable Transmission Densitometer*
iCPlate II — Portable Plate Reader
InkFormulation — Software
IntelliTrax — Scanning Pressroom Spectrophotometer*
IntelliTrax 2 — Scanning Pressroom Spectrophotometer

J

Judge II — Light Booth*
Judge QC — Light Booth

K

KeyWizard — Utility Software*

L

LightSpex — Radiometer*

M

MA-T12 — Portable Multi-Angle Spectrophotometer
MA-T6 — Portable Multi-Angle Spectrophotometer
MA-3 / MA-5 — Portable Multi-Angle Spectrophotometer
MA48 — Portable Multi-Angle Spectrophotometer
MA68ii — Portable Multi-Angle Spectrophotometer
MA94 — Portable Multi-Angle Spectrophotometer
MA98 — Portable Multi-Angle Spectrophotometer
MatchRite Database Converter — Utility Software
MatchRite iVue — Non-contact Benchtop Spectrophotometer
MatchStik RM110 — Portable Color Matching Instrument*
MatchStik Connect RM130 — Utility Software*
Measure Tool 5 — Profiling Software*
MetaVue — Non-contact Benchtop Spectrophotometer
MonacoOPTIX — Profiling Software*
MonacoPROFILER Gold — Profiling Software*
MonacoPROFILER Platinum — Profiling Software*
Monaco QC Color Client — Quality Assurance Software*
Monaco QC Color Server — Quality Assurance Software*
Monaco QC Color Software — Quality Assurance Software*

N

NetProfiler — Quality Assurance Software

P

Pantone 3 Lightbooth — Light Booth
Pantone Color Manager — Utility Software
Pantone Huey — Display Calibration Hardware & Software*
PantoneLIVE Design — Digital Pantone Libraries
PantoneLIVE Production For Print and Packaging — Digital Pantone Libraries
Pantora Software — TAC Material Hub Software
Personal Designer — Utility Software*
PlateQuality Flexo — Plate Analysis Software*
ProfileEditor 5 — Profiling Software*
ProfileMaker 5 — Profiling Software*
ProfilerMaker 5 Packaging — Profiling Software*
Prooflite — Luminary*
Pulse ColorElite — Portable Scanning Colorimeter*

Q

QUIKDens 100 — Portable 0°/45° Densitometer*
QUIKDens 200 — Portable 0°/45° Densitometer*

R

RM61 — Portable 0°/45° Spectrophotometer*
RM200QC — Portable Imaging Spectrocolorimeter
RM400 — Tethered 0°/45° Spectrophotometer
RM425 — Tethered 0°/45° Spectrophotometer*

S

SP52 — Portable Sphere Spectrophotometer*
SP62 — Portable Sphere Spectrophotometer*
SP64 — Portable Sphere Spectrophotometer*
SpectraLight III — Light Booth*
SpectraLight QC — Light Booth
SpectroEye — Portable 0°/45° Spectrophotometer*
Spectrofiler — Automated Color Measurement System*
Spectrolino — Automated Color Measurement System
Spectroscan — Automated Color Measurement System

T

X Rite I1 Display Pro Software Download For Windows

TabWizard II — Utility Software
TAC Services — Color & Appearance Services
TAC7 — Imaging Scanner for the TAC Ecosystem
TeleFlash 130 — Non-contact Industrial Spectrophotometer
TeleFlash 445 — Non-contact Industrial Spectrophotometer
TeleFlash Compact — Non-contact Industrial Spectrophotometer

V

Vericolor Solo — Non-contact Industrial Colorimeter
VeriColor Spectro — Non-contact Industrial Spectrophotometer
VeriColor System — Non-contact Industrial
VipFlex — Benchtop Plate Reader*
VipFlex 2 — Benchtop Plate Reader*
VipPAQ — Non-contact Flexo Web Scanner*
Virtual Light Booth — Simulation Software for Tac Ecosystem
VS450 — Non-contact Benchtop Spectrophotometer
VSWin — Quality Assurance Software

W

I1profiler Download Mac Os

W Series Retail Solutions — Retail Paint Solutions

X

Xrite I1 Software

I1profiler Download Mac Download

XColor QC — Quality Assurance Software
XRite PrintCheck — Quality Assurance Software
X-Rite ColorMaster Software — Quality Assurance Software

X Rite I1 Driver

i1Display Pro: Professional Display Calibration for the Most Demanding Color Perfectionists

X Rite I1 Pro Driver

I1profiler Download Mac Free

The X-Rite i1Display Pro is a calibration and profiling system for a display / projector. It helps to make sure that the colors on your display match those in your original picture or file. The i1Display features i1Profiler software for calibrating and profiling all modern display and projector technologies, including LED and Wide Gamut LCDs. It's also spectrally calibrated, which makes it field-upgradeable to support future display technologies. Using the free and downloadable ColorTRUE app for iOS and Android, the i1Display Pro may also be used to calibrate select phones and tablets.
The system's ergonomic design incorporates 3 functions - ambient light measurement, monitor profiling, and projector profiling - into a very sleek, compact and fully integrated device with no parts to misplace. Experience speeds up to 5X faster than previous devices! A custom-designed RGB filter set provides accurate color measurements, while the optical design allows for high repetition on the same display and across different display types for more consistent color matching. There's even a rotating diffuser arm that can be used as a stand for table top projector profiling, ambient light measurement, or as a cover for instrument optics. The conveniently integrated tripod mount is great for projector profiling in larger venues.
The i1Display offers both 'Basic' and 'Advanced' modes, giving you the power to choose which one is best for you. Basic mode offers a wizard-driven interface with predefined options for the quickest path to professional on-screen color. Advanced mode offers user-defined options for more sophisticated profiling workflows, to deliver the highest quality color results on monitors and projectors, as well as display testing and quality assurance tools.
Enjoy virtually infinite control of white point, luminance, contrast ratio, gamma and more, as well as multiple monitor and workgroup profiling. Intelligent Iterative Profiling is an adaptive technology that measures and analyzes the color capabilities of each unique display for increased profile accuracy. Create unique patch sets for optimal results in your profiling. Ambient Light Measurement automatically determines the optimum display luminance for comparing prints to your display, based on a measurement of the lighting conditions where the prints will be viewed. Ambient Light Smart Control performs measurement, compensation and ongoing monitoring of ambient lighting conditions, letting you decide whether you want the i1Display system to automatically adjust your profile or simply notify you as ambient light conditions change.
Flare Correct measures and adjusts your display profile for reduced contrast ratios caused by flare light (or glare) falling on the surface of your display. By accurately measuring your effective display contrast ratio, you'll have a more precise display profile. 3 patch set sizes - small, medium, or large - allow you to increase your profile accuracy by measuring a higher number of patches. Choose your own combination of patch set size, extracted colors from specific images and/or PANTONE spot colors selected from the included PANTONE Color Manager software. The Automatic Display Control (ADC) technology automates the adjustment of your display's hardware, including brightness/backlight, contrast, and color temperature, in order to speed up the profiling process and eliminate manual adjustments--so there's less work for you!
You can re-use profile settings on multiple displays connected to the same computer or to multiple computers within a workgroup. Before and after images show instant results, and the handy profile reminder lets you know when it's time to re-profile your display. Easy-to-follow on-screen help guides and videos mean there are no extra manuals needed.
When it comes to display quality assurance, this system can perform visual validation using pre-defined and user defined images. It can also do measurement-based validation in 3 different ways: Using industry standard targets and reference data sets (like SWOP, Gracol and Fogra), using PANTONE color and libraries, or using colors extracted from user defined images. You can also take advantage of user defined PASS/FAIL deltaE tolerance for average and maximum values. Additionally, the i1Display Pro features color accuracy trending over time. For a display uniformity test, measure white point and luminance uniformity over 9 locations on your display, and take control with user defined PASS/FAIL tolerance.
